A locking compression plate looks, at a glance, like any bone plate — a contoured strip of metal with a row of screw holes. The geometry of those holes is where the real engineering sits, and it's the difference between a plate that relies entirely on friction against bone and one that behaves like an internal, angular-stable scaffold.
Compression vs. locking: two different jobs
Conventional plating relies on compression — a standard screw is tightened until the plate is pulled down tight against the bone, and stability comes from friction at that plate-bone interface. Locking screws work differently: the screw head threads directly into the plate hole itself, creating a fixed-angle construct where the screw, plate and bone move as a single rigid unit, independent of how tightly the screw is torqued against the bone surface.
What "angular stable" actually means for the fracture
Because each locking screw is rigidly fixed to the plate at a set angle, the construct resists toggling and screw loosening even in bone with reduced density — a meaningful advantage in osteoporotic fracture patterns, where a conventional screw can strip its purchase and lose fixation entirely. The plate effectively becomes an internal fixator, spanning the fracture with a stable frame rather than depending on plate-to-bone friction along its full length.
The combi-hole design
Most modern LCPs use a "combi-hole" — a single plate hole engineered to accept either a conventional compression screw on one side or a locking screw on the other. This lets a surgeon dynamically compress a simple fracture line first, using standard screws to bring bone fragments together, then add locking screws elsewhere on the same plate for angular-stable fixation — combining both mechanisms in a single construct where the fracture pattern calls for it.
Why pre-contoured geometry matters more than it looks
A plate that must be manually bent in the operating room to match a patient's anatomy introduces variability — over-bending fatigues the metal and can create stress risers, while an imperfect fit changes the compression forces the construct actually delivers. Anatomically pre-contoured plates, matched to typical bone geometry at a given site (distal radius, proximal tibia, clavicle), reduce intra-operative bending, save time, and preserve the plate's designed mechanical performance.
Plate or nail: a design, not a preference, question
Locking plates and intramedullary nails both address fracture stabilisation, but the biomechanics differ — a nail sits on the bone's mechanical axis and shares load differently than a plate positioned eccentrically on the bone surface. The choice generally follows fracture location and pattern: nails are frequently favoured for long-bone shaft fractures, while plates offer more flexibility for peri-articular, metaphyseal or irregular fracture geometry where precise fragment-level fixation is needed.
